high frequency PVC clear pillow boxes making machine PET soft crease box production

Brief Introduction

  • This is a strong power high frequency pvc welding machine. The peumatic drive moving control part assistant with hydraulic pressing and cutting system. There are two working positions under the welding heads.
  • It is good for double side blister welding with margin cutting work.
  • The popular model is: JC-5KWT, JC-8KWT, JC-10KWT, JC-12KWT , JC-15KWT.

Applications

  • high frequency pvc welding machine transparent plastic bags clear zipper bag making equipment.
  • high frequency PVC clear pillow boxes making machine. It is good for PET soft crease box production.
  • It is also suitable for embossing on handbag, small spraying toys,leather products,carpet,plastic inflatable products clothes and shoes embossing tool, trademark,box,air tool,carpet,package bag,heat water bag,medical treatment articles,stationary,photo album,physical good,pvc folding box,glass box,tent,etc.garment logo welding and shoe upper welding
radio frequency welding machine for pvc
radio frequency sealing machine factory
radio frequency sealing machine for pvc

Specifications:

  • Install high Q oscillation value in the machine which is stable and reliable in output.
  • sliding two working positions can be operated alternatively to improve the production
  • Pneumatic press system, max pressure can up to 800~1200KG
  • The oscillation frequency is authorized industrial frequency band of 27.12MHz ± 0.6%
  • Easy Operation–New design of toggle motion lever principle allows easy operation
  • Working voltage can be 3 phases, 380V/400V, 50/60Hz + ground or customized
  • This is most ideal for products which required complicated alignments.
  • NL-5557 high sensitive anti-flash device, prevent machine & mould from over current
  • With high precision temperature controlling can assure the coherence of welding

PVC blister sample

transparent pvc box

Latest Weld Samples

soft crease pvc box (2)

Reference working video

Specifications

5000WT specification

hf blister weld mold

clear plastic box mould
